SKF Lock Nut HM 3048 + MS 3048 And Locking Devices Adapters

HM lock nuts are used to locate bearings onto a shaft. They have metric trapezoidal threads and eight equally spaced slots located around their circumference to accommodate an impact spanner. They should be locked by a locking clip to prevent unintentional loosening. HM lock nuts can be reused, provided they are not damaged.

• Simple, stable and reliable fastening element

• Easy to install and remove

• Reusable with new locking clip

• Available for thread Tr 220x4 to Tr 1120x8 (sizes 44 to /1120)



• Dimensions

  Thread designation	Tr 240x4
  Bore diameter	9.449 in
  Outside diameter	11.417 in
  Width	1.339 in

• Properties

  Locking device	Locking clip
  Nut for hydraulic mounting	No
  Associated mounting tool	TMFN 40-52

• Logistics

  Product net weight	9.899 lb
  eClass code	23-11-07-05
  UNSPSC code	31163218
