7013 CYDU/GLP4
NACHI
| Quantity: | |
|---|---|
NACHI Bearing 7013 CYDU/GLP4, 65x100x36 MM
| Weight [kg] | 0.4700 |
|---|---|
| Inner diameter [mm] | 65.000 |
| Outer diameter [mm] | 100.000 |
| Width [mm] | 36.000 |
| Category | Spindle bearings |
| Seal | None |
| Radial Clearance | Normal |
| Bore | Cylindrical |
| Special | Spindle bearing |
| Customs tariff no. | 84828000 |
| Brand | NACHI |
| Seal | Without, open bearing |
| Temperature range | -30 to +100 °C |
| Preload | Light |
| Ball Rows | Double row bearing |
| Product type | Spindle bearings |
| Tolerance class | Tolerance class P4 / ABEC 7 |
| Lubrication hole | Without lubrication groove |
| Rolling elements material | Normal bearing steel |
| Lubrication | Preserved |
| Contact angle α | 15° |
| Material | Normal bearing steel |
| Cage type | Polyamide cage |
| Arrangement | Set of two universal bearings |
| Inner diameter [mm] | 65 |
| Outer diameter [mm] | 100 |
| Width [mm] | 36 |
